Hand Operated Hydraulic Pump With Gauge

Working Pressure(bar): Low Pressure stage: 0-20kg/cm ², High Pressure Stage:20-700kg/cm ².
Oil Displacement per stroke(cm3): Low Pressure stage:13cc, High Pressure Stage:2.3cc
Reservior(cm3): Oil capacity:1000, Usable oil capacity:700.
Hose Length: 1.8M
Product size: 600*120*240mm
Weight: 12.4kg
CE
Robust, durable and compact.
Two-speed hydraulic system for fast and easy operation.
Lower handle effort to minimize operator fatigue.
Large and comfortable release knob for improved control of pressure release.
Internal pressure relief valve for overload protection.
Working Pressure:
Low pressure stage-0-20kg/cm ²
High pressure stage-20-700kg/cm ²
Oil Displacement per stroke:
Low pressure stage - 13cc
High pressure stage - 2.3cc
Reservior
Oil capacity-1200cc
Usable oil capacity-700cc
Hose length: 1.8M
Can be used with split hydraulic products
