ENGINE
Engine Type 4 Strokes, OHV
Engine YF170FD
Displacement 192cc
Maximum Power 4.4 Kw
Rated Power 4.2Kw
Bore x Stroke 70 x 50mm
Condensation Ratio 8.5 : 1
Ignition System Transistor
Starting System Electric
Cooling System Forced air
Fuel Tank Capacity 6L
Lube oil Capacity 0.6L
GENERATOR (CT5605)
Max. Power 3.5Kw
Rated Power 3.2Kw
AC Voltage 110V/29.1A
AC Frequency 60Hz
Rated DC Output 12V/8.3A
Waved Distortion < 2.5%
Power factor 1
Insulation Grade F
Performance Grade G2
Working Hour 8Hr@25% LOAD
Sound Pressure Level 96dB(A)
Nosied Level @ 7m(1/4 load) 61dB(A)
